FEATURES:
- High Performance 10x optical system with low dispersion glass
- Integrated thread-in throw leaver for quick magnification changes
- Illuminated MSR BDC-10 reticle with 11x brightness levels
- Lay flat flip-back lens covers included
- Dependable waterproof, shockproof, and fog-proof performance
- Includes ALPHA-MSR one-piece aluminum cantilever mount
Specifications:
Magnification |
1-10x |
Objective Lens Diameter |
26 mm |
Weight |
21.9 oz |
Illumination Settings |
11 |
Maintube Diameter |
34mm |
Total Elevation Travel |
100 MOA |
Total Windage Travel |
100 MOA |
Travel Per Rotation |
44 MOA |
Eye Relief Low (IN) |
87.5 |
Eye Relief High (IN) |
82.5 |
Field of View Low (FT @ 100 Yards) |
120 |
Field of View High (FT @ 100 Yards) |
12 |
Diopter Adjustment Range |
+/- 2.5 |
Objective Outer Diameter |
34 MM |
Mount Included |
Yes |
Battery |
(1) CR2032 |
Focal Plane |
First |
Reticle |
MSR BDC10 |
Illumination |
Yes |
Item Number: SOTM11202
